Titon FireSafe® Double Air Brick

Fire Resistant Air Brick

The original Titon FireSafe® Air Brick Range is an award-winning unique high flow terminal designed for powered ventilation systems offering low resistance to airflow, but high resistance to fire as set out in Approved Document B (fire safety) volume 1: Dwellings, 2019 edition incorporating 2020 and 2022 amendments.  Constructed from sheet steel (A1) and polyester powder coated to classification A2-s1, d0.

NBS Source logo

The Titon FireSafe® Double Air Brick is designed to be built into external wall types during construction. The range consists of short and long versions and can easily be connected to 220×90 rectangular ducting.

TA364,TA365,TA372,TA373,TA374,TA375,TA366,TA384,TA364,TA372,TA374,TA364,TA365,TA372,TA373,TA374,TA375

Features & Benefits

  • Polyester Powder Coating meeting EN13501-1 classification A2-s1,d0
  • Material 1.2mm Electrogalvanized Sheet Steel, fire class A1 ‘no contribution to fire’
  • Designed for 220×90 ducting
  • Bezelled version for use with exterior cladding instead of brickwork
  • Complies with the latest standard as set out in Approved Document B (fire safety) volume 1: Dwellings, 2019 edition incorporating 2020 and 2022 amendments
  • High flow terminal designed for powered ventilation systems offering low resistance to airflow and high resistance to fire
  • Extensive versatile range for different installation options
  • Single size option available
  • Registered Design
  • Special paint finishes available depending on quantity
  • Performance tested to BS EN13141-2:2010
  • Corrosion resistance – salt spray tested to BS EN ISO 9227:2012
  • Optional lengths available at request
  • Compatible with thermal and rigid ducting
  • CIBSE accredited CPD course available

Technical Information

Product Codes and Specific features

Titon FireSafe® Double Air Brick

Product Codes

TA364 – Titon FireSafe® Air Brick 204x128x100/
TA365 – Titon FireSafe® Air Brick 204x128x100 Bezelled

TA372 – Titon FireSafe® Air Brick 204x128x400/
TA373 – Titon FireSafe® Air Brick 204x128x400 Bezelled

TA374 – Titon FireSafe® Air Brick 204x128x500/
TA375 – Titon FireSafe® Air Brick 204x128x500 Bezelled

Accessories
TA366 – Transition 204×128 to 220×90
TA384 – Metal Sleeve 220x90x400

Specifications

Materials: Steel Electrolytically Zinc Coated (BS EN 10152 DC01 ZE25/25)

Paint: Powder Coated (A2-s1, d0 classification to EN 13501-1)

Registered Design
TA364 – Registered Design No 6080907
TA372 – Registered Design No 6080908
TA374 – Registered Design No 6080908

Finishes: Terracotta, Sand, Grey, White or Brown

Colour Reference (add to end of part number)

Product Colours
/023 – Brown (Semigloss RAL 8017)
/086 – Terracotta (Matt RAL 8004)
/151 – White (Matt RAL 9010)
/397 – Grey (Matt RAL 7012)
/626 – Sand (Matt RAL 1001)

Accessories Colours
/687 – Traffic White (Semigloss RAL 9016)

Installation: Install in accordance with Residential Ventilation Association Good Practice recommendations – details on request.

Maintenance: Wipe with a damp cloth and remove any blockages on a regular basis.

Free Area:
TA364, TA365, TA372, TA373, TA374 & TA375
Titon FireSafe® Air Brick AAO = 20,111 mm²


204x128x100



TA364 – Titon FireSafe® Air Brick 204x128x100/
TA365 – Titon FireSafe® Air Brick 204x128x100 Bezelled
With
TA366 – Transition 204×128 to 220×90
*Resistance curve – air brick and accessory combined.


204x128x400 and 204x128x500





TA372 – Titon FireSafe® Air Brick 204x128x400/
TA373 – Titon FireSafe Air Brick 204x128x400 Bezelled

TA374 – Titon FireSafe® Air Brick 204x128x500/
TA375 – Titon FireSafe® Air Brick 204x128x500 Bezelled
With
TA366 – Transition 204×128 to 220×90
*Resistance curve – air brick and accessory combined.


TA364, TA372, TA374 – Titon FireSafe® Double Air Brick

Product
Size
Part
Number
 B C Weight
204x128x100 TA364 100 209 129 2.2
204x128x400 TA372 400 209 129 4.8
204x128x500 TA374 500 209 129 5.7

TA365, TA373, TA375 – Titon FireSafe® Double Air Brick

Product
Size
Part
Number
 B C Weight
204x128x100 TA365 100 209 129 2.4
204x128x400 TA373 400 209 129 5
204x128x500 TA375 500 209 129 5.8

Bezel – 204×128 Version

TA366 – Transition 204×128 to 220×90
Weight – 1.4kg

TA384 – Metal Sleeve 220x90x400
Weight – 2.5kg
