Titon FireSafe® 100mm Push Through Wall Kit

Circular Fire Resistant Terminal

The new Titon FireSafe® 100mm Push Through Wall Kit is an Award winning circular high flow terminal designed for powered ventilation systems offering low resistance to airflow, but high resistance to fire as set out in Approved Document B (fire safety) volume 1: Dwellings, 2019 edition incorporating 2020 and 2022 amendments.

Ideal for new build, refurbishment and social housing residential applications, it is constructed from sheet steel (A1) and polyester powder coated to classification A2-s1, d0.

Titon FireSafe® 100mm Push Through Wall Kit is designed to be installed from the inside of the dwelling and will create a seal to the external wall.

The range consists of a Ø100 round version at 630mm long.

Book a CPD

TA425

Features & Benefits

  • Constructed from 0.6mm electrogalvanized sheet steel (A1) and polyester powder coated (terminal only) to classification A2-s1, d0.
  • Polyester powder coating meeting EN13501-1 classification A2-s1,d0
  • Ideal for retrofit where mould and condensation are a major problem
  • Designed for installation with Titon Ultimate® dMEV
  • Can be cut to desired wall thickness
  • Performance tested to BS EN13141-2:2010
  • Corrosion resistance – salt spray tested to BS EN ISO 9227:2012
  • Special paint finishes available depending on quantity
  • Compatible with thermal and rigid ducting
  • Compatible with Titon’s range of MEV fans
  • Rubber round gasket to seal with external wall
  • Complies with the latest standard as set out in Approved Document B (fire safety) volume 1: Dwellings, 2019 edition incorporating 2020 and 2022 amendments
  • High flow terminal designed for powered ventilation systems offering low resistance to airflow and high resistance to fire

Technical Information

Product Codes and Specific features

Titon FireSafe® 100mm Push Through Wall Kit

Product Codes

TA425 – Titon FireSafe® 100mm Push Through Wall Kit, Ø100 and 630mm long

Specification

Materials:
Hot Dipped Galvanised Steel

Paint:
Powder Coated (A2-s1, d0 classification to EN 13501-1)

Rubber Gasket:
Thermoplastic Elastomer (TPE)

Finishes: Terracotta and White*

Colour Reference (add to end of part number)
/086 – Terracotta (Matt RAL 8004)
/151 – White (Matt RAL 9010)

*Terminal only (excluding ducting) and other colours available at request.



Installation:
Install in accordance with Residential Ventilation Association Good Practice recommendations – details on request.

Maintenance: Wipe with a damp cloth and remove any blockages on a regular basis.

Free Area:
AAO = 6174 mm²


TA425 – Titon FireSafe® 100mm Push Through Wall Kit
