Titon FireSafe® Single Air Brick

Fire Rated Air Brick

The original Titon FireSafe^® Air Brick Range is an award-winning unique high flow fire-rated terminal designed for powered ventilation systems offering low resistance to airflow, but high resistance to fire as set out in Approved Document B (fire safety) volume 1: Dwellings, 2019 edition incorporating 2020 and 2022 amendments. The metal air brick is constructed from sheet steel (A1) and polyester powder coated to classification A2-s1, d0.

The Titon FireSafe^® Single Air Brick is designed to be built into external wall types during construction. The range consists of short and long versions and can easily be connected to both 204×60 and 220×90 rectangular ducting.

Book a CPD

TA360,TA361,TA370,TA371,TA380,TA381,TA390,TA391,TA392,TA393,TA362,TA382,TA383,TA385,TA363,TA384

Features & Benefits

Material 1.2mm Electrogalvanized Sheet Steel, fire class A1 ‘no contribution to fire’
Polyester Powder Coating meeting EN13501-1 classification A2-s1,d0
Equivalent to many brick sized grilles and additional brick and half size option
Designed for both 204×60 & 220×90 ducting
Bezelled version for use with exterior cladding instead of brickwork
Complies with the latest standard as set out in Approved Document B (fire safety) volume 1: Dwellings, 2019 edition incorporating 2020 and 2022 amendments
High flow terminal designed for powered ventilation systems offering low resistance to airflow and high resistance to fire
Extensive versatile range for different installation options
Double sized option available
Registered Design
Special paint finishes available depending on quantity
Performance tested to BS EN13141-2:2010
Corrosion resistance – salt spray tested to BS EN ISO 9227:2012
Optional lengths available at request
Compatible with thermal and rigid ducting
CIBSE accredited CPD course available

Technical Information

Product Codes and Specific features

Product Codes and Specificiation

Titon FireSafe^® Single Air Brick

Product Codes

TA360 - Titon FireSafe^® Air Brick - 204x60x100
TA361 - Titon FireSafe^® Air Brick - 204x60x100 Bezelled

TA370 - Titon FireSafe^® Air Brick - 204x60x400
TA371 - Titon FireSafe^® Air Brick - 204x60x400 Bezelled

TA380 - Titon FireSafe^® Air Brick - 330x60x100
TA381 - Titon FireSafe^® Air Brick - 330x60x100 Bezelled

TA390 - Titon FireSafe^® Air Brick - 330x60x400
TA391 - Titon FireSafe^® Air Brick - 330x60x400 Bezelled

TA392 - Titon FireSafe^® Air Brick - 330x60x500
TA393 - Titon FireSafe^® Air Brick - 330x60x500 Bezelled

Accessories
TA362 - Metal 45° Bend 204x60
TA382 - Metal 45° Bend 330x60

TA383 - Metal Transition 330x60 to 220x90
TA385 – Metal Transition 330x60 to 220x90 Flat Top Profile

TA363 - Metal Sleeve 204x60x200
TA384 - Metal Sleeve 220x90x400

Specification

Materials: Steel Electrolytically Zinc Coated (BS EN 10152 DC01 ZE25/25)

Paint: Powder Coated (A2-s1, d0 classification to EN 13501-1)

Registered Design
TA360 - Registered Design No 6067647
TA370 - Registered Design No 6067645
TA380 - Registered Design No 6067648
TA390 - Registered Design No 6067646
TA392 - Registered Design No 6067646

Finishes: Terracotta, Sand, Grey, White or Brown

Colour Reference (add to end of part number)

Product Colours
/023 - Brown (Semigloss RAL 8017)
/086 - Terracotta (Matt RAL 8004)
/151 - White (Matt RAL 9010)
/397 - Grey (Matt RAL 7012)
/626 - Sand (Matt RAL 1001)

Accessories Colours
/687 - Traffic White (Semigloss RAL 9016)

Installation: Install in accordance with Residential Ventilation Association Good Practice recommendations – details on request.

Maintenance: Wipe with a damp cloth and remove any blockages on a regular basis.

Free Area:
Small Air Bricks - TA360, TA361, TA370 & TA371
Titon FireSafe^® Air Brick - AAO = 10089 mm²

Large Air Bricks - TA380, TA381, TA390, TA391, TA932 & TA393
Titon FireSafe^® Air Brick - AAO = 16060 mm²

High Flow Terminal Resistance

204x60x100

TA360 - Titon FireSafe^® Air Brick - 204x60x100/
TA361 - Titon FireSafe^® Air Brick - 204x60x100 Bezelled

TA360 - Titon FireSafe^® Air Brick - 204x60x100/
TA361 - Titon FireSafe^® Air Brick - 204x60x100 Bezelled
with
TA362 - Titon FireSafe^® Air Brick - 45° Bend 204x60
*Resistance curve - air brick and accessory combined.

204x60x400

TA370 - Titon FireSafe^® Air Brick - 204x60x400/
TA371 - Titon FireSafe^® Air Brick - 204x60x400 Bezelled

TA370 - Titon FireSafe^® Air Brick - 204x60x400/
TA371 - Titon FireSafe^® Air Brick - 204x60x400 Bezelled
with
TA362 - Titon FireSafe^® Air Brick - 45° Bend 204x60
*Resistance curve - air brick and accessory combined.

330x60x100

TA380 - Titon FireSafe^® Air Brick - 330x60x100/
TA381 - Titon FireSafe^® Air Brick - 330x60x100 Bezelled

TA380 - Titon FireSafe^® Air Brick - 330x60x100/
TA381 - Titon FireSafe^® Air Brick - 330x60x100 Bezelled
with
TA382 - 45° Bend 330x60 and
TA383 - Transition 330x60 to 220x90
TA385 - Metal Transition 330x60 to 220x90 Flat Top Profile
*Resistance curve - air brick and accessory combined.

330x60x400 and 330x60x500

TA390 - Titon FireSafe^® Air Brick - 330x60x400/
TA391 - Titon FireSafe^® Air Brick - 330x60x400 Bezelled

TA392 - Titon FireSafe^® Air Brick - 330x60x500/
TA393 - Titon FireSafe^® Air Brick - 330x60x500 Bezelled

TA390 - Titon FireSafe^® Air Brick - 330x60x400/
TA391 - Titon FireSafe^® Air Brick - 330x60x400 Bezelled

TA392 - Titon FireSafe^® Air Brick -330x60x500/
TA393 - Titon FireSafe^® Air Brick - 330x60x500 Bezelled

with

TA382 - 45° Bend 330x60 and
TA383 - Transition 330x60 to 220x90
*Resistance curve - air brick and accessory combined.

Drawings and Dimensions

TA360, TA370, TA380 & TA390 - Titon FireSafe^® Single Air Brick

Product Size	Part Number	A	B	Weight
204x60x100	TA360	100	208.8	1.2
204x60x400	TA370	400	208.8	3
330x60x100	TA380	100	330	1.8
330x60x400	TA390	400	330	4.3
330x60x500	TA392	500	330	5.2

TA361, TA371, TA381 & TA391 - Titon FireSafe^® Single Air Brick

Product Size	Part Number	A	B	Weight
204x60x100	TA361	100	208.8	1.3
204x60x400	TA371	400	208.8	3.1
330x60x100	TA381	100	330	2
330x60x400	TA391	400	330	4.5
330x60x500	TA393	500	330	5.4
