Overture DH Stainless Steel
Lever door handle range
A high performance range of stainless steel door handles suited with Overture E window handles. Available in sprung lever/lever and lever/pad variations.
TN8108,TN8109,TN8003/099,TN8004/009
Technical Information
Product Codes and Specific features
Details
| Product | Door Width (mm) | Product Code Stainless Steel - 304 |
| Overture SS L2/L2 (Door Handle Long Baseplate Lever2/Lever2) | 40-70 | TN8108 |
| Overture SS L2/P2 (Door Handle Long Baseplate Lever2/Pad2*) | 40-70* | TN8109 |
NB: Reduction of spindle and/or screws may be required to achieve the full door width range
| Door Thickness (mm) | Product Code |
| 44 | TN 8003/099 |
| 70 | TN 8004/009 |
Manufactured from:
Stainless steel 304
Zinc alloy cradle
Standards:
BS EN 1670 Grade 5 (480 hours)
Cycle tested to 100,000 cycles as per EN1906: 2002
Finishes:
NOTE: Not all products are available in all finishes listed below. Please contact us for availability.
Suffix product code with: -102 (PVD Gold), -812 (Polished Chrome), -825 (Satin Chrome)
